The Intertechnik CO30/1.50/060 is a high purity, thermoplastic insulated copper foil choke coil.
Highlights
- High CU Purity of >99.99%
- Thermoplastic insulation for added durability
- 1.5mH inductance with a 5% tolerance
- Resistance of 0.84Ω and 23 AWG wire size
Product details
I.T. Intertechnik CO30/1.50/060 | 1,5 mH | 0,84 Ω | 5% | 23 AWG | Choke Coil
This Intertechnik CO30/1.50/060 choke coil is a highly efficient component used in crossover networks. It's designed with a copper purity of over 99.99%, ensuring excellent electrical conductivity. It's insulated with thermoplastic for enhanced durability and is capable of enduring temperatures between -90 and 135 degrees Celsius. The coil has a nominal inductance of 1.5mH with a tolerance of -3%. Its resistance measures 0.84 ohms, and it's built with 23 AWG wire. The wire connection length is 50 mm, and the tinning length is 9 mm. This coil is ideal for reducing noise and preventing damage to sensitive components.
I.T. Intertechnik artikelnummer: 1500105
