The I.T. Intertechnik CO30/1.80/060 is a high-quality choke coil with a 1.8 mH inductance and a resistance of 0.96 Ω.
Highlights
- Inductance of 1.8 mH for optimal performance.
- Low resistance of 0.96 Ω to ensure efficient energy transfer.
- Manufactured with copper purity > 99.99% for superior conductivity.
- Thermoplastic insulation to withstand extreme temperatures.
Product details
I.T. Intertechnik CO30/1.80/060 | 1,8 mH | 0,96 Ω | 5% | 23 AWG | Choke Coil
The I.T. Intertechnik CO30/1.80/060 is a top-tier choke coil designed specifically for crossover components. It boasts a precise inductance of 1.8 mH and a low resistance of 0.96 Ω, ensuring minimal energy loss and optimal performance. Manufactured with copper of more than 99.99% purity, it provides superior electrical conductivity. The coil is insulated with thermoplastic, enduring temperatures from -90 to 135 degrees Celsius, making it suitable for rigorous conditions. With a wire connection length of 50 mm and tinning length of 9 mm, it ensures ease of installation. The coil body is made of polycarbonate, promising durability and longevity. It stands out for its inductance tolerance of -3%, measured at nominal 25 degrees Celsius and 1 kHz Cu, providing unmatched reliability in its category.
I.T. Intertechnik artikelnummer: 1500106
