Name: Intertechnik CO44/100/050 | 10 mH | 3,48 Ω | 5% | 24 AWG | Tube Core Coil
Brand: Intertechnik
SKU: CO44/100/050
Price: 18.45 EUR
Availability: InStock

CO44/100/050 | 10 mH | 3,48 Ω | 5% | 24 AWG | Tube Core Coil

€ 15,25€ 18,45 5 Op voorraad

Gratis verzending vanaf € 99
Voor 16u besteld, vandaag verstuurd
Ten minste twee jaar garantie
45 dagen bedenktijd voor retourneren

Klantbeoordeling:

Vergelijk

Zakelijke offerteaanvraag

Heeft u vragen over dit product?

Onze klantenservice helpt u graag verder!

Productomschrijving Intertechnik CO44/100/050 | 10 mH | 3,48 Ω | 5% | 24 AWG

A high-quality Tube Core Coil from I.T. Intertechnik with a 10 mH inductance and 3.48 Ω resistance.

Highlights

High conductivity with CU purity over 99.99%
Inductance tolerance of +- 5%
Features a 24 AWG wire size
Constructed with a durable ABS bobbin material

Product details

I.T. Intertechnik CO44/100/050 | 10 mH | 3,48 Ω | 5% | 24 AWG | Tube Core Coil

This tube core coil from I.T. Intertechnik is a top-of-the-line product in the category of Crossover components Coils Copper foil coils. With an inductance of 10 millihenries and a resistance of 3.48 ohms, it offers excellent electrical performance. The coil comes with a wire size of 24 AWG and features a high CU purity of over 99.99%, ensuring optimal conductivity. It is equipped with a wire connection length of 10 mm and a tinning length of 9 mm. The coil's core can be Corobar or Ferrobar, and the inductance tolerance is +- 5%. The coil measures nominal 25 degrees C at 1 kHz. The spool is made of durable ABS material, ensuring long-lasting performance.

I.T. Intertechnik artikelnummer: 1340976
