A high-quality, precision-engineered Tube Core Coil from I.T. Intertechnik with 8.2 mH inductance and 2.27 Ω resistance.
Highlights
- High precision with a tolerance of ±5%
- Exceptional CU Reinheit of > 99.99%
- Constructed with superior ABS spool body material
- Features Corobar or Ferrobar core shape
Product details
I.T. Intertechnik CO44/8.2/060 | 8,2 mH | 2,27 Ω | 5% | 23 AWG | Tube Core Coil
This I.T. Intertechnik CO44/8.2/060 Tube Core Coil is a significant component in your crossover system. With an inductance of 8.2 mH and a resistance of 2.27 Ω, it accurately filters frequencies and delivers an excellent audio experience. It offers a low tolerance of ±5%, ensuring optimal performance and consistency. Made with a high CU Reinheit greater than 99.99%, this coil guarantees exceptional conductivity. It is incorporated with a Corobar or Ferrobar core shape and housed in a robust ABS spool body. The coil's wire connection length is 10 mm, and its tin-plated length is 9 mm. This tube core coil is perfect for applications that require precision and quality.
I.T. Intertechnik artikelnummer: 1340974
