Productomschrijving Intertechnik CO55/220/060 | 22 mH | 4,26 Ω | 5% | 23 AWG

A high-grade Tube Core Coil of 22 mH, 4.26 Ω, and 5% tolerance, designed for crossover components.

Highlights

High inductance value of 22 mH
Impressive resistance of 4.26 Ω
Precision ensured with 5% tolerance
Constructed with CU Reinheit of > 99.99% purity

Product details

I.T. Intertechnik CO55/220/060 | 22 mH | 4,26 Ω | 5% | 23 AWG | Tube Core Coil

The I.T. Intertechnik CO55/220/060 is a high-grade Tube Core Coil, specifically designed for crossover components in the realm of copper foil coils. With an inductance value of 22 mH and resistance of 4.26 Ω, it guarantees high performance and efficiency. It adheres to a tolerance of 5%, ensuring precision and reliability in its operation. The coil is made from CU Reinheit with a purity of more than 99.99%, ensuring high conductivity and minimal energy loss. It features a 10 mm wire connection length and a 9 mm tinning length. The coil body is made from ABS, a robust material known for its durability. The core is available in either Corobar or Ferrobar formats. The nominal inductance measurement is taken at 25 degrees C and 1 kHz.

I.T. Intertechnik artikelnummer: 1340984
