An efficient 10mH, 0.68 ohm, 5% Ferrobar Coil from I.T. Intertechnik for crossover components.
Highlights
- 10mH inductance with a tolerance of 5%
- 0.68 ohm resistance
- 19 AWG wire thickness
- Made from high purity copper >99.99%
Product details
I.T. Intertechnik DR56/100/095 | 10 mH | 0,68 Ω | 5% | 19 AWG | Ferrobar Coil
This product is an I.T. Intertechnik DR56/100/095 Ferrobar Coil, perfect for crossover components. It offers 10mH inductance with a tolerance of 5%, and a resistance of 0.68 ohms, making it ideal for your specific needs. The coil is made with a copper wire of 19 AWG, which ensures durability and excellent signal transmission. The high purity of the copper wire, with a purity of over 99.99%, ensures minimal signal loss. The coil is encased in a Ferrobar core, which enhances its inductive properties and is made from ABS for durability. The wire is tinned at lengths of 9mm, 35mm and 45mm, and the wire connection length is 10mm, 40mm and 50mm. The coil operates optimally at a nominal temperature of 25 degrees Celsius.
I.T. Intertechnik artikelnummer: 1340860
