        DR56/15/132 | 15 mH | 0,531 Ω | 5% | 16 AWG | Ferrobar Coil

        Intertechnik DR56/15/132 | 15 mH | 0,531 Ω | 5% | 16 AWG | Ferrobar Coil

        €62,95

        Niet op voorraad

        Toevoegen aan winkelwagen

        Intertechnik DR56/15/132 | 15 mH | 0,531 Ω | 5% | 16 AWG | Ferrobar Coil

        0 reviews
        0 van 5
        0 reviews
        5 sterren
        0%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        Merk: Intertechnik
        Toon alle Koperfoliespoelen
        DR56/15/132 | 15 mH | 0,531 Ω | 5% | 16 AWG | Ferrobar Coil
        DR56/15/132 | 15 mH | 0,531 Ω | 5% | 16 AWG | Ferrobar Coil
        DR56/15/132 | 15 mH | 0,531 Ω | 5% | 16 AWG | Ferrobar Coil
        DR56/15/132 | 15 mH | 0,531 Ω | 5% | 16 AWG | Ferrobar Coil
        € 62,95 Niet op voorraad
        +-
        Toevoegen aan winkelwagen
        • Gratis verzending vanaf € 99
        • Snel weer op voorraad
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        DR56/15/132 | 15 mH | 0,531 Ω | 5% | 16 AWG | Ferrobar Coil
        DR56/15/132 | 15 mH | 0,531 Ω | 5% | 16 AWG | Ferrobar Coil
        DR56/15/132 | 15 mH | 0,531 Ω | 5% | 16 AWG | Ferrobar Coil
        DR56/15/132 | 15 mH | 0,531 Ω | 5% | 16 AWG | Ferrobar Coil

        Productomschrijving Intertechnik DR56/15/132 | 15 mH | 0,531 Ω | 5% | 16 AWG

        A high-performing Ferrobar coil by I.T. Intertechnik, ideal for crossover components in audio equipment.



        Highlights

        • High copper purity of over 99.99% for exceptional conductivity.
        • Inductance value of 15mH with a tolerance of ±5% for precise audio frequency response.
        • Constructed with Ferrobar ferrite for high electrical resistance.
        • 16 AWG wire size for robustness and durability.



        Product details

        I.T. Intertechnik DR56/15/132 | 15 mH | 0,531 Ω | 5% | 16 AWG | Ferrobar Coil



        The I.T. Intertechnik DR56/15/132 Ferrobar Coil is a top-tier component for audio crossover systems. It boasts a high copper purity of more than 99.99%, ensuring excellent conductivity and signal transmission. The coil's inductance value is 15mH, with a tolerance of ±5%, guaranteeing accurate audio frequency response. Constructed with a Ferrobar ferrite core, it offers high electrical resistance, contributing to the coil's overall performance and durability. The coil features a wire size of 16 AWG, providing robustness and longevity. The wire has a length of 40mm, and the tin-plated section measures 9mm, offering ample connections for your audio equipment. With its ABS spool body material, it promises stability and resilience. Choose the I.T. Intertechnik DR56/15/132 for a high-quality, reliable audio crossover component.



        I.T. Intertechnik artikelnummer: 1340849

        Specificaties

        Artikelnummer
        DR56/15/132
        EAN
        8785256850013
        Spoeltype
        Copper foil coils
        Inductie
        15 mH
        Gelijkstroomweerstand
        0.531 ohms
        Tolerantie
        5%
        Draaddiameter
        16 AWG
