Name: Intertechnik HQ40/1.8/095 | 1,8 mH | 0,26 Ω | 5% | 19 AWG | Roller Core Coil
Brand: Intertechnik
SKU: HQ40/1.8/095
Price: 16.25 EUR
Availability: InStock

HQ40/1.8/095 | 1,8 mH | 0,26 Ω | 5% | 19 AWG | Roller Core Coil

€ 13,43€ 16,25 4 Op voorraad8 verwacht op 12-11-2024

Gratis verzending vanaf € 99
Nu besteld, dinsdag bezorgd
Ten minste twee jaar garantie
45 dagen bedenktijd voor retourneren

Klantbeoordeling:

Vergelijk

Zakelijke offerteaanvraag

Heeft u vragen over dit product?

Onze klantenservice helpt u graag verder!

Productomschrijving Intertechnik HQ40/1.8/095 | 1,8 mH | 0,26 Ω | 5% | 19 AWG

The I.T. Intertechnik HQ40/1.8/095 is a 1.8mH Roller Core Coil with a resistance of 0.26 Ω.

Highlights

High copper purity of >99.99%
ABS spool body material
Ferrobar ferrite core
Inductance tolerance of +- 5%

Product details

I.T. Intertechnik HQ40/1.8/095 | 1,8 mH | 0,26 Ω | 5% | 19 AWG | Roller Core Coil

The I.T. Intertechnik HQ40/1.8/095 is a roller core coil that belongs to the category of crossover components coils copper foil coils. It features an inductance of 1.8mH and a resistance of 0.26 Ω. The HQ40 model uses copper wire with a diameter between 0.85 - 1.60 mm and a purity of more than 99.99%. The wire connection length varies between 10, 40, and 50mm, and the tinning length varies between 9, 35, and 45mm. The spool body material is made of ABS, and the core shape is Ferrobar ferrite. The inductance tolerance is +- 5% and the inductance measurement is Nom. 25 degrees C Cu. 1 kHz FERROBAR (R). This product offers high performance and reliability for your audio needs.

I.T. Intertechnik artikelnummer: 1340115
