The I.T. Intertechnik HQR32/2.7/60 is a top-tier tube core coil designed to deliver 2.7 mH inductance with high precision.
Highlights
- Offers 2.7 mH inductance.
- Features a resistance of 1.23 Ω.
- Constructed with 23 AWG copper wire.
- Guarantees a tolerance of +/- 5%.
Product details
I.T. Intertechnik HQR32/2.7/60 | 2,7 mH | 1,23 Ω | 5% | 23 AWG | Tube Core Coil
The I.T. Intertechnik HQR32/2.7/60 is a premium tube core coil in the category of Crossover components Coils Copper foil coils. Engineered for precision, it delivers an inductance of 2.7 mH and a resistance of 1.23 Ω. The coil is constructed from 23 AWG copper wire with a purity greater than 99.99%, ensuring excellent conductivity. The coil features a wire connection length of 10 mm and a tinning length of 9 mm. The coil body is crafted from durable ABS material, and the core is available in either Corobar or Ferrobar. This coil is designed to operate optimally at a nominal 25 degrees Celsius and 1 kHz. With a tolerance of +/- 5%, this coil ensures accurate performance in your audio crossover system.
I.T. Intertechnik artikelnummer: 1340962
