Name: Intertechnik LU25/010/060 | 0,1 mH | 0,29 Ω | 3% | 23 AWG | Choke Coil
Brand: Intertechnik
SKU: LU25/010/060
Price: 5.45 EUR
Availability: InStock

LU25/010/060 | 0,1 mH | 0,29 Ω | 3% | 23 AWG | Choke Coil

€ 4,50€ 5,45 6 Op voorraad

Gratis verzending vanaf € 99
Nu besteld, dinsdag bezorgd
Ten minste twee jaar garantie
45 dagen bedenktijd voor retourneren

Klantbeoordeling:

Vergelijk

Zakelijke offerteaanvraag

Heeft u vragen over dit product?

Onze klantenservice helpt u graag verder!

Productomschrijving Intertechnik LU25/010/060 | 0,1 mH | 0,29 Ω | 3% | 23 AWG

I.T. Intertechnik LU25/010/060 is a high-purity copper air core coil.

Highlights

Features 0.1 mH inductance
Offers 0.29 Ω resistance
Comes with 3% inductance tolerance
23 AWG wire gauge

Product details

I.T. Intertechnik LU25/010/060 | 0,1 mH | 0,29 Ω | 3% | 23 AWG | Choke Coil

The I.T. Intertechnik LU25/010/060 is a robust air core coil used particularly in crossover components. It offers a significant inductance of 0.1 mH and a resistance of 0.29 Ω. The coil has been designed with a 3% inductance tolerance and a 23 AWG wire gauge, guaranteeing efficiency and reliability. The coil is composed of high-purity copper (>99.99%) with a wire diameter of 0.90 - 1.32 mm and is secured with Thermoplastic insulation. The coil terminals have a length of 50mm and a tinning length of 9mm. The coil body is made from high-grade Polycarbonate, capable of withstanding temperatures from -90 to 135 degrees Celsius. This product is perfect for individuals seeking superior performance and durability.

I.T. Intertechnik artikelnummer: 1500054
