The I.T. Intertechnik LU44/010/100 Air Coil is a high-quality crossover component with a 0.1 mH inductance and a 0.14 Ω resistance.
Highlights
- 0.1 mH inductance for effective crossover performance
- 0.14 Ω resistance ensures minimal energy loss
- 3% inductance tolerance for precise sound reproduction
- Constructed with 18 AWG wire for durability
Product details
I.T. Intertechnik LU44/010/100 | 0,1 mH | 0,14 Ω | 3% | 18 AWG |Air Coil
The I.T. Intertechnik LU44/010/100 is a top-of-the-line air coil designed for crossover components. It boasts an inductance of 0.1 mH, a resistance of 0.14 Ω, and an inductance tolerance of 3%. This coil is constructed using 18 AWG wire, ensuring its durability and longevity. The coil measurements were taken at a nominal temperature of 25 degrees Celsius at 1KHz. The air coil features a wire connection length of 10 mm and a tin-plating length of 9 mm. The coil form material is made of ABS, providing optimal sound reproduction and reliability. This product is perfect for those seeking superior sound quality and performance in their audio systems.
I.T. Intertechnik artikelnummer: 1340002
