This is an I.T. Intertechnik LU44/1.00/071 Air Coil, a high-quality crossover component for superior audio performance.
Highlights
- Features a 1.0 mH inductance with a 3% tolerance
- Comes with a low resistance of 0.94 Ohms
- Uses 21 AWG wire for optimum signal transmission
- Constructed with ABS coil body material for durability
Product details
I.T. Intertechnik LU44/1.00/071 | 1,0 mH | 0,94 Ω | 3% | 21 AWG |Air Coil
The I.T. Intertechnik LU44/1.00/071 is a top-of-the-line air core coil designed for use in crossover components. With a specific inductance of 1.0 mH and a tight tolerance of -3%, it ensures accurate frequency response for your audio system. The coil features a low resistance of 0.94 Ohms, allowing for maximum power transfer and minimal signal loss. It uses a 21 AWG wire, ensuring high signal integrity and optimal audio performance. The coil is constructed from ABS material, known for its durability and resistance to wear. The wire connection length is 10 mm, with a tinning length of 9mm, which allows for easy and secure connections. This air coil is tested at a nominal 25 degrees C at 1KHz, guaranteeing reliable performance under standard operating conditions.
I.T. Intertechnik artikelnummer: 1700507
