The I.T. Intertechnik LU55/1.0/100 is a high-quality air coil for crossover components.
Highlights
- 1.0 mH inductance
- 0.60 ohms resistance
- 3% inductance tolerance
- 18 AWG wire gauge
Product details
I.T. Intertechnik LU55/1.0/100 | 1,0 mH | 0,60 Ω | 3% | 18 AWG |Air Coil
The I.T. Intertechnik LU55/1.0/100 is a top-notch air coil designed for crossover components. It comes with a 1.0 mH inductance and 0.60 ohms resistance, demonstrating a high level of accuracy with a tolerance of 3%. The coil uses 18 American Wire Gauge (AWG), ensuring superior electrical conductivity and minimal power loss. The coil is made with ABS plastic, a durable and heat-resistant material, ensuring long-term reliability and performance. Measured at nominal 25 degrees C at 1KHz, this air coil guarantees consistent performance across various conditions. The coil also features a 10 mm wire connection length and a 9mm tinning length, providing ease of installation and secure, reliable connections.
I.T. Intertechnik artikelnummer: 1340026
