This I.T. Intertechnik LU78/2.2/140 Air Coil provides exceptional performance for crossover components with its 2.2 mH inductance and 0.46 Ω resistance.
Highlights
- 2.2 mH inductance
- 0.46 Ω resistance
- Measurements taken at nominal 25 degrees C
- Manufactured with 15 AWG wire
Product details
I.T. Intertechnik LU78/2.2/140 | 2,2 mH | 0,46 Ω | 3% | 15 AWG |Air Coil
The I.T. Intertechnik LU78/2.2/140 Air Coil provides a precise inductance of 2.2 mH and a resistance of 0.46 Ω, ensuring optimal performance for crossover components in audio systems. Crafted with a wire gauge of 15 AWG and an ABS spool body material, this air coil ensures durability and excellent electrical characteristics. It features a wire connection length of 10 mm and a tinning length of 9 mm. The air coil operates within a tolerance of 3%, with measurements taken at a nominal 25 degrees C at 1KHz, guaranteeing reliable and consistent performance. This product symbolizes the fusion of high-quality materials and advanced technology.
I.T. Intertechnik artikelnummer: 1340064
