        Productomschrijving Peerless by Tymphany HDS-P830860 Bass-midwoofer

        The Peerless High Definition Sound (HDS) Series offers high-quality solutions for multi-way speaker systems employing vented box alignments.



        Highlights

        • Truncated cast aluminum frame
        • PPB polypropylene cone with half-roll rubber surround
        • Long-throw voice coil
        • Shorting rings for reduced distortion
        • Under-spider and voice coil ventilation



        Product details



        Peerless by Tymphany 830860 5-1/4" PPB Cone HDS Woofer



        The Peerless High Definition Sound (HDS) Series offers high-quality solutions for multi-way speaker systems employing vented box alignments. A powerful ferrite magnet system is coupled to a finite element analysis-designed suspension system, containing a linear spider design and rubber surround. The motor incorporates an aluminum shorting ring that reduces coil inductance, extending frequency response performance and reducing second harmonic distortion. A cast aluminum basket provides high structural rigidity, heat-sinking capacity for the motor, and additional ventilation under the spider that in combination with a vented cone neck reduces air compression effects. Peerless developed the proprietary and highly advanced Polypropylene Black (PPB) cone material used in the HDS PPB Series, creating a stiff but still dampened cone that remains stable even under the greatest sound pressures.

        Toon meer

        Specificaties

        Artikelnummer
        HDS-P830860
        EAN
        0844632084010
        Woofer series
        Peerless by Tymphany HDS series
        Woofer type
        Midwoofer
        Nominale diameter
        5-1/4"
        Belastbaarheid (RMS)
        30 Watts
        Belastbaarheid (max)
        60 Watts
        Impedantie (Z)
        8 Ohms
        Gevoeligheid (SPL bij 1m / 2.83V)
        85.8 dB
        Frequentierespons
        60 to 5,000 Hz
        Spreekspoeldiameter
        1"
        Gelijkstroomweerstand (Re)
        5.9 ohms
        Spreekspoelinductie (Le)
        0.27 mH
        Resonantiefrequentie (Fs)
        62 Hz
        Mechanische Q (Qms)
        2.21
        Elektrische Q (Qes)
        0.59
        Totale Q (Qts)
        0.47
        Bewegende massa (Mms)
        9g
        Compliantie van de ophanging (Cms)
        0.74 mm/N
        Effectief oppervlak (Sd)
        89.9 cm²
        Krachtsfactor (BL)
        5.9 Tm
        Equivalentvolume (Vas)
        0.3 ft.³
        Maximale excursie (Xmax)
        3.5 mm
        Cone / Diaphragm Material
        Poly
        Surroundmateriaal
        Rubber
        Mand- /framemateriaal
        Cast Aluminum
        Magneetmateriaal
        Ferrite
        Totale buitendiameter
        5.99"
        Totale diepte
        2.76"
        Montagegatdiameter
        4.72"
        # Bevestigingsgaten
        6
        Gesloten volume
        0.1 ft.³
        Gesloten F3
        117 Hz
        Gepoort volume
        0.31 ft.³
        Gepoort F3
        64 Hz

        Toon meer

        Reviews

        3 reviews
        Schrijf een review
        5 van 5
        Klanglich ist nichts zu klagen. Angaben zu Schalldruck sind uneinheitlich und nicht mit früheren Produktspezifikationen vergleichbar. Voll geeignet als Ersatz für einen älteren Kalottenmitteltöner der einen deutlich höheren Schalldruck angab. Bohrung ist 12 cm, das findet sich nicht im Datenblatt. Die 51/4 Zoll betrifft wohl die abgeflachten Seiten und nicht den Kreisdurchmesser.
        Door Dominikus on 26 November 2024
        5 van 5
        Very clear and dynamic midrange sound! Very high quality sound, even at high power. It has relative tight suspension and starts distortion at really high input power. It has a rising frequency response towards higher frequency, and requires proper crossover as any other driver, but Troles did a good job I think: I have built Troles Gravesen PPB-830860 kit with Peerless DX25 tweeter, and I am more than satisfied. I think it is a perfect driver fo...

        Toon meer

        Door Benedek, Hungary on 16 September 2023
