        SB26STC-C000-4 Textil-Kalottenhochtöner

        SB Acoustics SB26STC-C000-4 Textil-Kalottenhochtöner

        €32,45

        10+ Op voorraad

        Toevoegen aan winkelwagen

        SB Acoustics SB26STC-C000-4 Textil-Kalottenhochtöner

        5 reviews
        5 van 5
        5 reviews
        5 sterren
        100%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        Merk: SB Acoustics
        Toon alle SB Acoustics tweeters
        1" | 4 Ω
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        € 26,82€ 32,45 10+ Op voorraad
        • -5% Bestel 4 voor slechts € 30,83 per stuk
        +-
        Toevoegen aan winkelwagen

        Buy now, pay later

        • Gratis verzending vanaf € 99
        • Nu besteld, morgen bezorgd
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner
        SB26STC-C000-4 Textil-Kalottenhochtöner

        Productomschrijving SB Acoustics SB26STC-C000-04 Dome Tweeter

        The SB Acoustics SB26STC-C000-4 Textile Dome Tweeter is a surprisingly well designed tweeter for its price. The 1’’ tweeter has a low resonance frequency allowing for a lower crossover point and better integration.



        Highlights

        • Copper cap for reduced voice coil inductance and minimum phase shift
        • Non-reflective rear chamber with optimized damping for improved dynamics
        • Flow optimized vented pole piece for optimum coupling to rear chamber
        • Fine weave soft fabric dome for smooth frequency response
        • Saturation controlled motor system for low distortion
        • CCAW voice coil for low moving mass
        • Long life silver lead wires
        • Low resonance frequency



        Product details

        SB Acoustics SB26STC-C000-4 1'' Tweeter



        The SB Acoustics SB26STC-C000-4 tweeter has a large rear chamber lowering the fs to 750Hz and reducing back wave reflections from the dome. Its copper cap pole piece, coated textile dome, 1” voice coil and the recessed faceplate give it a partially horn loaded profile. A very linear response, high efficiency output at 91.5dB sensitivity and extension past 35,000Hz make it an excellent tweeter for larger two-way speakers.



        Specifications: BL Product (BL): 1.6 Tm • Diaphragm Mass Inc. Airload (Mms): 0. 3 g • Maximum Linear Excursion (Xmax): 0.6 mm • Surface Area of Cone (Sd): 6.2 cm2

        Toon meer

        Specificaties

        Artikelnummer
        SB26STC-C000-04
        EAN
        0691046948526
        Tweeter type
        Dome
        Cone / Dome Diameter
        25 mm | 1"
        Belastbaarheid (RMS)
        120 Watts
        Impedantie (Z)
        4 Ω
        Gevoeligheid (SPL bij 1m / 2.83V)
        91.5 dB
        Frequentierespons
        1400 to 35,000 Hz
        Resonantiefrequentie (Fs)
        750 Hz
        Gelijstroomweerstand (Re)
        3.2 ohms
        Voice Coil Inductance (Le)
        0.04 mH
        Mechanische Q (Qms)
        3
        Electromagnetic Q (Qes)
        1.78
        Totale Q (Qts)
        1.12

        Toon meer

        Reviews

        5 reviews
        Schrijf een review
        5 van 5
        Buyed these tweeters for a dipole mod, it work perfectly.
        Door Vittorio on 13 Oktober 2024
        5 van 5
        Very high Q/P ratio. Easy to use, I suggest 2.8 kHz 12dB/ octave filter as minimum fc, but this tweeter will never disappoint you, especially if you think about how much you paid for it. The sound is generally sweet and never harsh or annoying, but we should not expect the same resolution of a Satori beryllium tweeter or an Ellipticor or an Exotic....
        Door Vittorio Alberti on 8 Oktober 2024
