        Productomschrijving Scan-Speak Discovery 22W/4534G00 Woofer

        The Scan-Speak Discovery 22W/4534G00 is a 8-inch 4-ohm woofer that is designed for high-performance audio applications. It features a coated NRSC glass fiber cone, a low-damping SBR rubber surround, and an aluminum ring magnet system. The woofer has a low resonance frequency of 30 Hz, which makes it well-suited for reproducing deep bass sounds. It also has a high sensitivity of 92.4 dB, which means that it can produce a lot of sound for its size.



        Highlights

        • Coated NRSC fiberglass cone
        • Low-damping SBR rubber surround
        • Die-cast aluminum chassis
        • High sensitivity
        • Low resonance frequency
        • Large displacement



        Product details

        Scan-Speak Discovery 22W/4534G00 Woofer



        The Discovery 22W/4534G00 Woofer has a Coated NRSC fiberglass cone. This cone material is known for its excellent stiffness-to-mass ratio, which results in low distortion and good sound quality. Low-damping SBR rubber surround: This surround material provides a good balance of compliance and damping, which helps to improve the woofer's frequency response and transient response.



        This woofer has a high sensitivity of 92.5 dB, which means that it requires less power to produce a given level of sound output. It also has a low resonance frequency of 30 Hz, which makes it well-suited for reproducing low-frequency sounds. And it has a large displacement of 95 liters, which means that it can move a lot of air and produce a lot of sound output.

        Toon meer

        Specificaties

        Artikelnummer
        22W/4534G00
        EAN
        8785256848362
        Woofer series
        Scan-Speak Discovery series
        Woofer type
        Discovery
        Belastbaarheid (RMS)
        70 Watt
        Belastbaarheid (max)
        120 Watt
        Impedantie (Z)
        4 Ohm
        Gevoeligheid (SPL bij 1m / 2.83V)
        92.5 dB
        Frequentierespons
        30-5000 Hz
        Spreekspoeldiameter
        38 mm
        Gelijkstroomweerstand (Re)
        3 Ohm
        Resonantiefrequentie (Fs)
        30 Hz
        Mechanische Q (Qms)
        3.70
        Elektrische Q (Qes)
        0.37
        Totale Q (Qts)
        0.34
        Bewegende massa (Mms)
        23.7 g
        Compliantie van de ophanging (Cms)
        1.23 mm/N
        Effectief oppervlak (Sd)
        235 cm2
        Krachtsfactor (BL)
        6 Tm
        Equivalentvolume (Vas)
        95.0 L
        Maximale excursie (Xmax)
        12 mm
        Driver's Mechanical Losses (Rms)
        1.19 kg/s
        Cone / Diaphragm Material
        Fibre Glass
        Mand- /framemateriaal
        Aluminium
        Totale buitendiameter
        225 mm
        Totale diepte
        89.7 mm
        Montagegatdiameter
        184.7 mm
        Gepoort volume
        74 Litres
