        Excel W19NX001 - E0076-08 Graphene Woofer

        SEAS Excel W19NX001 - E0076-08 Graphene Woofer

        €649,95

        2 Op voorraad

        SEAS Excel W19NX001 - E0076-08 Graphene Woofer

        0 reviews
        0 van 5
        0 reviews
        5 sterren
        0%
        4 sterren
        0%
        3 sterren
        0%
        2 sterren
        0%
        1 ster
        0%
        Bekijk alle reviews
        Merk: SEAS
        € 537,15€ 649,95 2 Op voorraad
        • -5% Bestel 4 voor slechts € 617,45 per stuk

        Buy now, pay later

        • Gratis verzonden (NL & BE)
        • Nu besteld, morgen bezorgd
        • Ten minste twee jaar garantie
        • 45 dagen bedenktijd voor retourneren
        • Klantbeoordeling:
        Zakelijke offerteaanvraag
        Heeft u vragen over dit product?

        Heeft u vragen over dit product?

        Onze klantenservice helpt u graag verder!

        Voor- en nadelen

        Volgens onze specialisten
        • The precision cast, machined and Graphene treated magnesium cone acts as a piston through the working frequency band without showing any sign of midrange resonances
        • A unique radial reinforced rubber surround reduces radial resonances and prevents surround break up at large excursions

        Productomschrijving SEAS W19NX001 - E0076-08 Woofer

        The SEAS W19NX001 - E0076-08 Woofer is a high-performance woofer that features a precision cast, machined, and graphene-treated magnesium cone, a titanium voice coil former, and a unique radial reinforced rubber surround. This combination of components results in a woofer that is capable of producing accurate, detailed, and powerful bass response.



        Highlights

        • Precision cast, machined, and graphene-treated magnesium cone
        • Titanium voice coil former
        • Radial reinforced rubber surround
        • Nominal impedance of 8 ohms
        • Recommended frequency range of 30-3000 Hz
        • Short-term power handling of 360 watts
        • Long-term power handling of 200 watts
        • Sensitivity of 85.6 dB



        Product details

        SEAS Excel W19NX001 - E0076-08 Graphene Woofer



        The graphene-treated magnesium cone is very light and stiff, which helps to reduce resonances and improve clarity. The titanium voice coil former is also very light and strong, which helps to improve transient response. The radial reinforced rubber surround provides a good balance of damping and compliance, which helps to ensure that the woofer can produce deep, powerful bass without distorting.



        The SEAS W19NX001 - E0076-08 Woofer has a nominal impedance of 8 ohms and a recommended frequency range of 30-3000 Hz. It can handle up to 360 watts of short-term power and 200 watts of long-term power. The woofer is also relatively efficient, with a sensitivity of 85.6 dB.

        Toon meer

        Specificaties

        Artikelnummer
        W19NX001
        EAN
        8785256848768
        Woofer type
        Graphene Woofer
        Nominale diameter
        176 mm, 6.5 inch
        Belastbaarheid (RMS)
        200 Watt
        Belastbaarheid (max)
        360 Watt
        Impedantie (Z)
        8 Ohm
        Gevoeligheid (SPL bij 1m / 2.83V)
        85.6 dB
        Frequentierespons
        20-2000 Hz
        Spreekspoeldiameter
        39 mm
        Gewicht magneet
        0.90 kg
        Gelijkstroomweerstand (Re)
        6.2 Ohm
        Spreekspoelinductie (Le)
        0.23 mH
        Resonantiefrequentie (Fs)
        34 Hz
        Mechanische Q (Qms)
        5.30
        Elektrische Q (Qes)
        0.45
        Totale Q (Qts)
        0.41
        Moving Mass Of Diaphragm (Mmd)
        23.1 g
        Compliantie van de ophanging (Cms)
        0.95 mm/N
        Effectief oppervlak (Sd)
        136 cm2
        Equivalentvolume (Vas)
        24 Litres
        Maximale excursie (Xmax)
        26 mm
        Spreekspoel draadmateriaal
        Copper
        Spreekspoel vormermateriaal
        Titanium
        Totale buitendiameter
        176 mm
        Totale diepte
        80.7 mm
        Montagegatdiameter
        153 mm
        # Bevestigingsgaten
        6

        Toon meer
